CLX20
CLX24
CL3-12
CL3-12
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance *2 |
|---|---|---|---|---|---|
| A150, A120, A100, A75, A65, 175CR, 135CR, 105CR, 104CR | ***/CL3/12 | ***/CL3/12/P | M12 | 10mm (+/- 5mm) | 21kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CL3/12 | 22mm | 46mm | 25mm | 51mm | 0.23kgs |
CL3-16
CL3-16
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance *2 |
|---|---|---|---|---|---|
| A150, A120, A100, A75, A65, 175CR, 135CR, 105CR, 104CR | ***/CL3/6 | ***/CL3/16/P | M16 | 10mm (+/- 5mm) | 38kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CL3/12 | 22mm | 46mm | 25mm | 51mm | 0.23kgs |
CL4-16
CL4-16
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance *2 |
|---|---|---|---|---|---|
| A150, A120, A100, A75, A65, 175CR, 135CR, 105CR, 104CR | ***/CL4/16 | ***/C4/16/P | M16 | 12mm (+/- 6mm) | 62kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CL4/16 | 37mm | 51mm | 29mm | 51mm | 0.32kgs |
CL4-20
CL4-20
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance *2 |
|---|---|---|---|---|---|
| A150, A120, A100, A75, A65, 175CR, 135CR, 105CR, 104CR | ***/CL4/20 | ***/C4/120/P | M20 | 12mm (+/- 6mm) | 75kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CL4/20 | 37mm | 51mm | 29mm | 51mm | 0.32kgs |
CLX20
CLX20
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance *2 |
|---|---|---|---|---|---|
| A150, A120, A100, A75, A65, 175CR, 135CR, 105CR, 104CR, | ***/CLX20 | ***/CLX20/P | M20 | 20mm (+/- 10mm) | 98 kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CLX20 | 46mm | 70mm | 38mm | 65mm | 0.68kgs |
CLX22
CLX22
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance *2 |
|---|---|---|---|---|---|
| A150, A120, A100, A75, A65, 175CR, 135CR, 105CR, 104CR | ***/CLX22 | ***/CLX22/P | M22 | 20mm (+/- 10mm) | 116 kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CLX22 | 46mm | 70mm | 38mm | 65mm | 0.68kgs |
CLX24
CLX24
A single bolt adjustable crane rail clip that features a circular cam that locks the clip into position against the rail. The clip is designed and performs as a bearing connection.
| Popular Rails | No Pad | Pad | Bolt Dia. | Adjustment | Lateral Resistance |
|---|---|---|---|---|---|
| A150, A12O, A100, A75, A65, 175CR, 135CR, 105CR, 104CR | ***/CLX24 | ***/CLX24/P | M24 | 20mm (+/- 10mm) | 134 kN |
Clip capacity will vary with the bolt diameter, grade of the bolt and the design of the total connection.
Other rail sizes are available.
REPLACEMENT CLIP TOPS & RUBBER PRESSURE BLOCKS
Molyneux International rail clip tops are unique. When the rubber pressure block needs to be replaced, only the rubber component is replaced and not the entire clip top. To find out more contact our teams
| Clip | Height | Footprint | A | Length | Weight |
|---|---|---|---|---|---|
| CLX24 | 50mm | 74mm | 38mm | 65mm | 0.73kgs |
Assembly Instructions
Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium, totam rem aperiam,Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium, totam rem accusantium doloremque laudantium, totam
Install the bolt through the runway steel
Position the clip body over the bolt and against the rail
Position the cam in the body and place the bolt through the eccentric hole
Rotate the cam to align the rail
Install the washer and nut, Torque the nut as required
